Product name:24W CREE LED Track Luminaire

Model:CNC-TL-02-A

----24W CREE LED Track Luminaire(Dimmable)

Options:

1, House Color: black or white

2, Beam Angle: 20/50degree

3, Dimmable: Dimmable or Non-dimmable

4, Track socket: 2 phases 2wires, 3 phases 3wires or 4 wires for option

5, AC110V/220V

Physical Size:

----Physical sizes of 24W CREE LED Track Luminaire(Dimmable)

Material: Aluminum Alloy

LED Qty: 12pcs

Lens:Transparent

Color Temperature: 2800-3200K, 5700-6300K

Lumen Efficiency: 75Lm/W

IP rating: IP20

PF: >0.97

Installation type: Rail-mounted

Operating Temperature: -20℃~45℃

Lamp weight: 1500g

Life span: 30,000Hours.

Specifications:

----light intensity at cool white of 24W CREE LED Track Luminaire(Dimmable)

----light intensity at cool white of 24W CREE LED Track Luminaire(Dimmable)

----Light intensity at warm white of 24W CREE LED Track Luminaire(Dimmable)

----light intensity at warm white of 24W CREE LED Track Luminaire(Dimmable)

----lux readings at cool white of 24W CREE LED Track Luminaire(Dimmable)

----lux readings at warm white of 24W CREE LED Track Luminaire(Dimmable)
